EDCO CPM10 10 Inch Gasoline Walk-Behind Crete-Planer
Crete-Planers level, remove, texture and groove concrete and asphalt surfaces. The 10" Planer is designed for aggressive removal applications like surface leveling and heavy coating removal.
FEATURES
- 10" working width will scarify approximately 500-700 sq. ft. per hour at Depth
Per Pass of 1/8" - 1/4" steel frame
- Heavy-duty, oversized bearings
- Weighs 299 lbs. with cutters
- Tethered emergency stop switch
- Gasoline or Electric models available
- Vacuum port standard for dust-free cutting
- 6-Shaft and 8-Shaft easy change, side-loading drums available
- Tungsten carbide or steel cutters available
Product Specifications
The EDCO CPM10 10 Inch Gasoline Walk-Behind Crete-Planer is a powerhouse in concrete surface preparation, designed for professionals who require aggressive removal, leveling, texturing, or grooving of concrete and asphalt surfaces. With its robust engineering, wide 10-inch cutting path, and high-powered Honda gas engine, the CPM10 is the contractor’s preferred choice for productivity, versatility, and ease of use on jobs from sidewalk trip hazard repair to warehouse renovation.
Product Overview
The CPM10 excels in demanding applications, offering a 10” working width and the ability to scarify 500–700 square feet per hour at 1/8” depth per pass. Equipped most commonly with a 13 HP Honda gasoline engine, this scarifier is built on a rugged, 1/4” steel frame with heavy-duty, oversized bearings and rear-mounted 6” wheels for maneuverability. The operator controls depth precisely with a screw hand wheel and can quickly change drums and cutter shafts for maximum jobsite efficiency.
Key Features
-
10” Working Width: Removes more material on every pass, increasing productivity on large jobs versus standard 8” scarifiers.
-
Depth Per Pass: Adjustable up to 3/8”, with a recommended 1/8” for best cutter and machine longevity.
-
Powerful 13 HP Gas Engine: Dependable Honda performance fuels deep, aggressive milling, even on weathered or thick-coated substrates.
-
Oversized Bearings and 1/4” Steel Frame: Built for tough jobsite abuse and years of heavy commercial use.
-
Vacuum Port Standard: Ready for industrial dust extraction, ensuring OSHA compliance and a cleaner, healthier jobsite.
-
Side-Loading Drum Assembly: Easy access for cutter drum swaps, supporting a variety of applications and rapid maintenance.
-
Larger Rear Wheels: 6” wheels make handling and transport easy, improving stability and reducing operator fatigue.
-
Multiple Drum and Cutter Options: Choose between 6-shaft and 8-shaft drums, with tungsten-carbide or steel cutters for maximum versatility.
-
Emergency Stop: Tethered kill switch for instant shut-off, maximizing safety.
Performance and Benefits
-
High Production Rates: Outpaces smaller scarifiers by 20–30%, reducing cost per square foot and maximizing labor hours.
-
Aggressive Removal: Ideal for eliminating thick coatings, heavy build-ups, weathered layers, or stubborn imperfections on slabs, parking decks, and plant floors.
-
Precise Control: Screw-type hand wheel and emergency stop provide perfect depth and quick response for both expert and new operators.
-
Long Tool Life: Oversized bearings, sealed compartments, and a robust frame resist wear, protecting your investment for years of demanding service.
-
Application Versatility: Cut grooves for slip resistance, remove epoxy or traffic lines, clean warehouse aisles, or repair sidewalk trip hazards—simply swap drum/cutter assembly as needed.
Maintenance Best Practices
-
Before Use: Check engine oil and air filter; inspect cutters/drum for wear. Tighten bolts and check belt tension—replace worn belts as a set for maximum performance.
-
Daily Cleaning: After each shift, remove dust and debris from the drum, vacuum port, bearings, and wheels. If water was used for dust control, immediately clean and dry the area under the planer to prevent slurry buildup.
-
Grease Bearings: Lubricate cutter assembly bearings every 4 hours. Grease the depth control every 40 hours for smooth operation and extended lifespan.
-
Cutter and Drum Care: Inspect all cutters regularly; rotate or replace for even wear and best finish. Only use drum/cutter types specified for the CPM10 series.
-
Belt Tensioning: New belts should be retensioned after the first 4 hours, then weekly or as needed. Never mix new and old belts.
-
Engine Maintenance: Follow Honda’s recommended intervals for oil, filter, and spark plug changes; clean the air filter daily in dusty conditions.
Safety Guidelines
-
Only operate outdoors or with adequate ventilation; never run gasoline engines indoors.
-
Attach emergency stop lanyard to your wrist or belt.
-
Wear eye, ear, respiratory, and hand protection.
-
Never service or inspect while running; shut down and allow all components to stop first.
-
Use vacuum dust control to prevent silica exposure.
Frequently Asked Questions
Q: How much material can the CPM10 remove per hour?
A: 500–700 sq. ft./hr. at 1/8” pass—performance depends on material hardness, cutter condition, and jobsite conditions.
Q: What drum/cutter configurations are available?
A: Six-shaft and eight-shaft drums fit tungsten-carbide and steel cutters; drums are side-loaded for easy change-outs.
Q: Is dust control included?
A: Yes, every CPM10 is vacuum-ready for dust-free operation. For additional silica control, use a HEPA-filtered industrial vacuum compatible with its 2" port.
Q: Can it be used for line removal?
A: Absolutely; CPM10 is a popular choice for traffic line/marking removal, leaving a profile ready for recoating or resurfacing.
Conclusion
The EDCO CPM10 10 Inch Gasoline Walk-Behind Crete-Planer is the industry’s choice for contractors demanding powerful, precise, and reliable scarifying on concrete and asphalt. Its 10" width, heavy Honda power, robust steel build, dust-ready engineering, and fast change-out drum design deliver the speed, control, and productivity today’s professionals count on for commercial, municipal, or industrial surface prep—making CPM10 a must-have for every serious jobsite.
